Main Giga B250M-D3H

Hãng sản xuất

Model

GA-B250M-D3H

Chipset

Intel® B250

CPU hỗ trợ

1. Support for 7th and 6th generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/Intel® Core™ i3 processors/ Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
2. L3 cache varies with CPU

RAM hỗ trợ

1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
   * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
2. Dual channel memory architecture
3. Support for DDR4 2400* / 2133 MHz memory modules
   * To support 2400 MHz or XMP memory, you must install a 7th generation processor.
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6. Support for Extreme Memory Profile (XMP) memory modules
   * To support 2400 MHz or XMP memory, you must install a 7th generation processor.

Đồ họa

1. Integrated Graphics Processor-Intel® HD Graphics support:
   1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
   2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
      * The DVI-D port does not support D-Sub connection by adapter.
   3. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
      * Support for DisplayPort 1.2 version.
   4. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
      * Support for HDMI 1.4 version.
   Support for up to 3 displays at the same time
   Maximum shared memory of 1 GB
2. 1. Support for AMD Quad-GPU CrossFireX™ and 2-Way AMD CrossFire™ Technology

Lưu trữ

1. 1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
   2. 1 x SATA Express connector
      * The SATA Express connector is not compatible with regular SATA devices.
   3. 6 x SATA 6Gb/s connectors
      * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Audio

1. Realtek® ALC892 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF Out

LAN

1. Intel® GbE LAN chip (10/100/1000 Mbit)

Khe cắm mở rộng

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
   (All of the PCI Express slots conform to PCI Express 3.0 standard.)
3. 2 x PCI slots

USB

1. Chipset:
   1. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
   2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

Kết nối I/O bên trong

1. 1. 1 x 24-pin ATX main power connector
   2. 1 x 8-pin ATX 12V power connector
   3. 1 x M.2 Socket 3 connector
   4. 1 x SATA Express connector
   5. 6 x SATA 6Gb/s connectors
   6. 1 x CPU fan header
   7. 3 x system fan headers
   8. 1 x front panel header
   9. 1 x front panel audio header
   10. 1 x S/PDIF Out header
   11. 1 x USB 3.1 Gen 1 header
   12. 2 x USB 2.0/1.1 headers
   13. 1 x Trusted Platform Module (TPM) header
   14. 1 x serial port header
   15. 1 x parallel port header
   16. 1 x Clear CMOS jumper

Kết nối bảng phía sau

1. 1. 1 x PS/2 keyboard/mouse port
   2. 1 x D-Sub port
   3. 1 x DVI-D port
   4. 1 x DisplayPort
   5. 1 x HDMI port
   6. 4 x USB 3.1 Gen 1 ports
   7. 2 x USB 2.0/1.1 ports
   8. 1 x RJ-45 port
   9. 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Theo dõi phần cứng

1. 1. Voltage detection
   2. Temperature detection
   3. Fan speed detection
   4. Overheating warning
   5. Fan fail warning
   6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

BIOS

1. 1. 2 x 64 Mbit flash
   2. Use of licensed AMI UEFI BIOS
   3. Support for DualBIOS™
   4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Phần mềm đi kèm

1. 1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      3D OSD
      @BIOS
      Ambient LED
      AutoGreen
      BIOS Setup
      Color Temperature
      Cloud Station
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      Platform Power Management
      Smart Backup
      Smart Keyboard
      Smart TimeLock
      System Information Viewer
      USB Blocker
      V-Tuner
   2. Support for 3TB+ Unlock
   3. Support for Q-Flash
   4. Support for Xpress Install

Hệ điều hành hỗ trợ

1. Windows® 10 64-bit (for 7th Generation Intel® Processors)
2. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
   * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.

Kích thước

1. Micro ATX Form Factor; 24.4cm x 22.5cm
